Scan&Go PRO

Scan&Go Pro is our advanced access control product range for vehicles and pedestrians. It offers the typical plug&play DAS-properties yet with more features than Scan&Go Basic:

  • Complex access rights for both short-term and long-term users
  • 1D & 2D barcode tickets/cards, RFID, ANPR, NFC...
  • Multi-access, multi-site, shared car parks & buildings
  • Remote control via web-based cloud application
  • Send eBarcodes via e-mail and scan your smartphone
  • Designed & engineered for installers.
  • Embedded VOIP intercom
Get In Touch

Scan&Go PRO components

We manufacture a wide range of aluminum housings and columns in-house in which we mount our Scan&Go Pro devices.​
Our aluminium columns and housings are by default powder-coated in RAL7016/7040. Other RAL colours are optional.​

T2 columns

Our modular aluminium Scan&Go Pro columns come with a width of 140mm and heights of 1180, 1680 and 2360mm for cars, pedestrians and trucks. T2 columns always come with a scanner configuration. Features as RFID readers and VOIP intercom are optional.

T6 columns​

Our modular aluminium T6 columns are available in two widths and three heights and can all be configured with both a front or back door. The double-width columns allow you to mount additional devices for which DAS can CNC-mill the openings. Columns come in scanner, printer and scanner/printer configurations. Embedded VOIP intercom and RFID are optional.

License plate recognition​

We mount Axis IP dome cameras with embedded Vaxtor ANPR software in our aluminum columns of only 200*100*600 mm. The low positioning of the dome camera allows easy installation (just behind the barrier cabinet) and high-performance reading. Installation and commissioning are done in record time.

Barcode Generators & Updaters

Unattended Barcode Updater (UBU)​

This column is the unattended on-foot variant of our ABU. Install this column at a strategic place and leave the updating or validating of a barcode to your customers. Just like our ABU, the UBU too can operate both standalone (two-tickets system) or online (one-ticket system).

Barcode printers

Thermal card and ticket printers with pre-configured push buttons that generate barcodes with a validity that is limited in time and number of uses. Grey button: Unlimited use until midnight. Blue button: Single use, 30 minutes. Use the free-of-charge configuration software AdminTool to change the default ticket layout and validity.

Attended Barcode Updater (ABU)

Have a barcode validated for the exit, transfer information from one barcode to another, grant a parking discount, … . The ABU can operate both standalone (two-ticket system) or online (one-ticket system).

Software

Virtual Printer PRO

Install this optional software on your PC and connect it to one of our desktop printers. Create as many virtual push buttons as you like. Assign a different validity and layout to all of them. Schedule visitors, e-mail them barcode invitations and have their self-printed or electronic (smartphone) barcode scanned at the entrance.

ProConnect

ProConnect is a cloud-hosted web application. It allows bi-directional communication with online DAS hardware. In one direction it uploads data such as: access events, alarms (hardware errors), revenue, …. . In the other direction it allows to: open a physical access remotely, change access rights from people, adjust ticket layouts, … .

SDK/API

Our Software Development Kit consists of a Windows DLL allowing to decode, interpret and generate DAS compatible barcodes so that third party products can interface with DAS. For instance, a POS supplier that is able to read DAS entry barcodes and that then generates till receipts that include a DAS exit barcode.

Surface-Mounted Housings

Vertical Mounting

Use this aluminum housing for both pedestrian and vehicle applications. The cabling and mounting holes are located on the back. Mount it to a full-height turnstile, a wall, a third party column, …. . By default powder-coated in RAL 7016/7040. RFID, embedded VOIP intercom and other RAL colours are optional.

Horizontal Mounting​

This aluminum housing is mainly used for pedestrian applications. Mount it for instance to a tripod turnstile, a desktop counter, … . The cabling and mounting holes are located on the bottom. By default powder-coated in RAL 7016/7040. Embedded VOIP intercom, RFID and other RAL colours are optional.

Electrical Power Is Enough

How Is This Possible?

Traditional Products

Traditional access control often needs a wired or wireless network. This implicates costly disadvantages as such solutions require cabling works, software and/or wireless communication devices.

Avoid Complexity

With Scan&Go you by default do not need any data network. Only electrical power. With this you avoid all the disadvantages of a wired or wireless solution mentioned above.

Choose S&G Efficiency

The ticket validity is encoded in the 2D code. As a result it is the 2D code that determines the duration and frequency of use of a ticket, without any data communication.

What Can

Scan&Go Pro Do For You?​

Create and assign access rights in a way that is specific to short-term and long-term vehicle and pedestrian users.

Extend your parking access installation with pedestrian access control and vice versa. You can use the same type of identifier everywhere and can assign up to three different identification tokens to one person (barcode, RFID and license plate).

The access (and payment) columns can operate standalone, but can also be networked and accessed via the cloud.

Choose one or more identification technologies that match the user type. For example, planned visitors and staff members can by default use ANPR with barcode or RFID or VOIP intercom as a redundant identifier.

Install an unlimited number of entry and exit columns on a single or on multiple sites, whether or not on shared parking lots and buildings. Through ProConnect every tenant can adjust her/his own configuration and generate reports, even if the hardware is common.

Create calendar schedules for regular users. Manage both planned and spontaneous (unexpected) visitors accordingly. Extend cost-efficiently your Scan&Go Pro-installation with Scan&Go Revenue devices, even with a low visitor frequency.
